- Industrial Inverter- DC/AC Converter
Hannibal Industrial Inverter Heavy-duty DC/AC Inverter, designed and developed to power critical loads in industrial environments such as Data Center and Server Rooms, Healthcare and Medical Equipment, Pharmaceutical, Oil, Gas, and Petrochemical Industries, Chemical, Power Generation and Distribution, Semiconductor, Automotive, & Renewable Energy and Telecommunication and IT.
Hannibal industrial inverters are fully customizable according to the Client’s needs. Single-phase or three-phase output and IGBT-based full bridge technology of the conversion units.
The inverter converts DC voltage into pure sinusoidal AC voltage with constant amplitude and stable frequency. The unit works with an IGBT inverter bridge with PWM (pulse width modulation) having high efficiency in the partial load range as well as achieving a low distortion factor at non-linear load.
Inverter output encompasses 6 IGBT modules, boosting the instant power capacity of the inverter by double fold with comparison to regular systems. This feature allows the inverter to handle higher capacity loads (inrush currents) with smaller capacity devices. In addition, switching at a high frequency – 16KHz – keeps the output sin wave (THD) undistorted providing reliable solutions for nonlinear loads.
Compatibel with Diesel Genrators and Ni-Cd Battery
Hannibal Industrial DC to AC converters can work easily with Diesel Generators like CAT Diesel Generators and if you can use any kind of battery like the Alcad and Saft Ni-CD / Enersys or Exide Lead Acid VRLA battery or OPZV/ OPZV
Industrial Inverter Specification
Hannibal Industrial Inverter can offer THD<3% and different kinds of filters like Anti Harmonic Filte- LC filter, RFI Filter, and also passive filters.
IGBT power modules are needed to convert electricity from one form to another so that the electricity can be more conveniently and safely used by all the digital devices that make up our modern lives.
Power modules become hot due to the heat loss in the conversion process and in some cases the losses are as great as 5%. For instance, in an electric vehicle, the losses may be as high as 10-15% which in turn impacts the range and performance of the vehicle.
For more details, you can see some related videos about DC/AC Inverter on our YouTube channel
Rating (kVA)* @ P.F. 0.8 vs DC Rated Voltage
48 Vdc** | 5 | 10 | 15 | 20 | 30 | 40 | – | – | – | – | – | – | – | – | – | – | – | – |
110 Vdc | 5 | 10 | 15 | 20 | 30 | 40 | 50 | 60 | 80 | 100 | – | – | – | – | – | – | – | – |
220 Vdc | 5 | 10 | 15 | 20 | 30 | 40 | 50 | 60 | 80 | 100 | 120 | 160 | 200 | 250 | 300 | – | – | – |
400 Vdc | – | – | – | – | – | – | – | – | – | 100 | 120 | 160 | 200 | 250 | 300 | 400 | 500 | 600 |
Nominal power kW | 4 | 8 | 12 | 16 | 24 | 32 | 40 | 48 | 64 | 80 | 96 | 128 | 160 | 200 | 240 | 320 | 400 | 480 |
Hannibal Industrial Battery charger(DC UPS or Rectifier)
Hannibal industrial battery charger is the modern power source for the electrical industry. Hannibal’s industrial rectifiers feature reliable, robust hardware and intelligent software functions. These products are developed with the customer and their business in mind. Continuity of process control is critical across many industrial markets. These include Data Centers and Server Rooms like IBM Power Servers, Dell PowerEdge Servers, Healthcare and Medical Equipment, like Siemens-healthiness products, Pharmaceutical, Oil, Gas, and Petrochemical Industries, Chemical, Power Generation and Distribution, Semiconductor like TSMC, Automation products like Emerson, & Renewable Energy and Telecommunication and IT usage like Axing products.
Also, Hannibal Industrial Battery Charger is the best solution for Switch tripping and SCADA systems like Ansys SCADE Suite, Low & High-voltage switchgear, and Gas-insulated switchgear (GIS) like Hitachi products, Transformers & SUB stations.
DC UPS (Industrial Rectifier) Specifications
This battery charger is a 6-pulse or 12-pulse thyristor-controlled, fully digital, static AC/DC rectifier. It offers constant voltage and current characteristics. This system resembles the DC part of our industrial UPS and includes a galvanic isolation transformer. The battery charger is SCADA-ready with free contacts and communication features, including Modbus protocol via RS-485 or TCP/IP port.
The Hannibal Industrial Battery Charger provides THD of less than 3% and offers various filters. These include anti-harmonic filters, LC filters, RFI filters, and passive filters. Additionally, if you are looking for an IGBT-based battery charger or rectifier, Hannibal can provide that as well.
Hannibal DC UPS and battery chargers are widely used in various industries. These include power generation, power distribution, power transmission, manufacturing, transportation, mining, and oil and gas. They serve different applications such as alarm, control, signal, and supply of DC breakers in power plants, substations, switchgear, railways, and offshore plants.
Ni-Cd and VRLA Battery Charger
These rectifiers are compatible with various battery types, including Alcad and Saft Ni-CD, as well as Enersys or Exide VRLA, OPzV, and Lithium-ion batteries. For DC voltage regulation, we use a dropper diode system as a DC-DC converter.
According to DIN 41773 standards, When functioning as a Ni-CD or VRLA battery charger, the system supports three charging modes:
– Float charge
– Equalizing charge
– Boost charge
DC-DC converter or DC Voltage Dropper Regulator
This item functions to reduce the voltage applied to the load. Without a dropper diode, the battery voltage (whether float or boost) directly affects the load. Consequently, if the float or boost voltage exceeds the load’s maximum operating voltage, the load may fail or suffer damage.
The dropper consists of diodes connected in series, which can be engaged or disengaged by a contractor. Therefore, the number of diodes and the steps in the dropper circuit depend on the load’s operating voltage range, the number of batteries, and the battery charge voltage (float and boost).
SD Series work in different DC Voltage range For Example:
220VAC/ 24V DC Battery Charger 220VAC/ 48V DC Battery Charger
220VAC/ 110V DC Battery Charger 3x380VAC/ 24V DC Battery Charger
3x380VAC/ 48V DC Battery Charger 3x380VAC/ 110V DC Battery Charger
3x380VAC/ 220V DC Battery Charger 3x380VAC/ 380V DC Battery Charger
Industrial UPS- PL Series
Hannibal Industrial UPS Power Supply
Hannibal Industrial Ups is designed for a high-reliability uninterruptible power supply. We are aware that the Industry should be robust and long-lasting. Hannibal Power and Technology has reliable experience in Industrial UPS power supply for control applications and harsh environments.
Continuity of process control is critical across a vast range of industrial markets: Data Center and Server Rooms, Healthcare and Medical Equipment, Pharmaceutical, Oil, Gas, and Petrochemical Industries, Chemical, Power Generation and Distribution, Semiconductor, Automotive, & Renewable Energy and Telecommunication and IT. Industrial UPS systems are designed for environments with prevalent fluctuations in electric power supply, power interruptions, and cuts.
Industrial AC UPS Specifications
With its customizable design, the PL Series is ultimately flexible for your requirements for a 3phase UPS Power Supply and Single phase from 3KVA to 2500KVA, with its user-friendly interface you can even apply your configuration changes. 20+ years of spare parts availability and 20+ years of design life will change your opinion on backup solutions.
Hannibal Industrial UPS is designed to meet the harshest electrical and mechanical conditions in industrial environments. Interchangeable sub-assemblies allow full customization, in compliance with the client’s technical specifications and the project’s documentation requirements.
If you are looking for Industrial UPS for Harsh weather and harsh environment Hannibal PL Series is the best option. Its high-grade protection level of up to IP66 ensures it works in every harsh condition. For more information please see Hannibal the Outdoor UPS. Modular board topology with hot swap operation enables you to carry out swift and effective maintenance and repair.
Hannibal dual online UPS can offer THD<3% and different kinds of filters like Anti Harmonic Filte- LC filter, RFI Filter, and passive filters.
According to the customer’s request, we can offer separate cabinets for the Rectifier and Inverter parts. Hannibal Industrial UPS can work with different battery types like Alcad or Saft Ni-CD / Yuasa VRLA/ Enersys OPZV/ OPZV/ Lithium ion,
PL Series AC UPSconsisted of 6 Pulse or 12 Pulse Thyristor Rectifier
If you are looking for an Industrial UPS with an IGBT Rectifier part please see our PLM series AC UPS.
Industrial UPS- PLM Series
Online Industrial UPS with Isolation Transformer
Hannibal Power and Technology PLM Series Industrial UPS is designed for high
reliability. We are aware that the Industry should be robust and long-lasting. Hannibal Group has reliable experience in Industrial UPS power protection for control applications and harsh environments.
Continuity of process control is critical across a vast range of industrial markets: Data Center and Server Rooms, Healthcare and Medical Equipment, Pharmaceutical, Oil, Gas, and Petrochemical Industries, Chemical, Power Generation and Distribution, Semiconductor, Automotive, & Renewable Energy and Telecommunication and IT. Industrial UPS systems are designed for environments with prevalent fluctuations in electric power supply, power interruptions, and cuts.
Transformer Base UPS Specifications
For this, we have come up with a brand new series combining robust technology of past and modern technology of control to maximize the outcome. Our goal is to keep your systems running 24/7.
Hannibal Industrial UPS can offer THD<3% and different kinds of filters like Anti Harmonic Filte- LC filter, RFI Filter, and also passive filters.
With its customizable design, the PLM Series is ultimately flexible for your requirements, with its user-friendly interface you can even apply your own configuration changes. 20+ years of spare parts availability and 20+ years of design life will change your opinion on backup solutions.
Hannibal UPS is designed to meet the harshest electrical and mechanical conditions in industrial environments. Interchangeable sub-assemblies allow full customization, in compliance with the client’s technical specifications and the project’s documentation requirements.
If you are looking for Industrial UPS for Harsh weather and harsh environment Hannibal PLM Series is the best option. Its high-grade protection level up to IP66 ensures it works in every harsh condition. Modular board topology with hot swap operation enables you to carry out swift and effective maintenance and repair.
According to the customer’s request, we can offer separate cabinets for the Rectifier and Inverter parts.
